Ashes of the Singularity PC Performance Review

DirectX 12 Features - Asynchronous Compute and Multi-GPU

Ashes of the Singularity PC Performance Review

DirectX 12 Features - Asynchronous Compute and Multi-GPU



Ashes of the Singularity is the first title to make use of two of the largest changes that DirectX 12 brings to the table, Asynchronous Compute and Explicit Multi-GPU support, which allows you to make better use of your GPU resources with advanced scheduling and allows you to make use of two non-matching GPUs in a Multi GPU setup respectively.

With older graphical APIs GPUs handled their loads with a single GPU schedule, meaning that they will only make do a single piece of work at a time, potentially leaving certain parts of your GPU at an idle state.  Asynchronous Compute allows compatible GPUs to handle parallel workloads, allowing your GPU to more efficiently schedule workloads and make sure that your GPU is making full use of its available compute resources, offering significant performance gains.

Right now only AMD GCN GPUs support Asynchronous Compute in their GPU drivers, though Nvidia is rumored to be adding support for this function to Maxwell in the future with a driver update, though this remains unconfirmed by Nvidia.



    One of the new and exciting features of the D3D12 is the ability to use multiple command queues on a single GPU. This feature is very similar to explicit Multi-GPUs. The idea here is that a GPU could have multiple graphics, compute and copy queues. This allows work to act parallel to each other, and for completed work to signal other work.

All of this is possible because Windows 10 has a sophisticated GPU scheduler which allows the OS to schedule commands to the GPU. Oxide is taking advantage of this advanced feature to allow us to enable not only the multi-GPU support, but to also even in single GPU schedule some of the work of the scene to be in parallel with other work in the scene. We’ve seen significant performance increases on some hardware by using the advanced scheduling capabilities of D3D12.





Ashes of the Singularity Beta Phase 2 DirectX 12 Performance Review

The second big change to DirectX 12 is how the API can make use of Multiple GPUs, for the first time allowing applications to interface with multiple GPUs directly.

In the past the APIs did not allow applications to look at multiple GPUs in a system, making the job of adding Multi-GPU (SLI or Crossfire) support a very difficult task, which often requires both specific driver profiles and a lot of work on the game side. This has resulted in the majority of PC games offering terrible multi-GPU support, but with DirectX 12 this job is made much simpler.

With DirectX 12 it is even possible to use several GPUs regardless of their manufacturer or product generation, allowing games that make use of this functionality to use multiple GPUs that traditionally would not work in a multi-GPU setup. This allows us to use both AMD and Nvidia GPUs in a single system and have them work together seamlessly, which is something that was simply not possible previously.



         Oxide is excited to release the first-ever game which uses the explicit multi-GPU abilities of D3D12. In previous APIs, the existence of multi-GPUs was largely hidden to the application. Thus, there was no ability for the application to drive multiple GPUs. D3D12 enables us explicit control over all GPUs in the system.

Thus, integrated directly into Ashes of the Singularity is the ability to do arbitrary AFR (alternate frame rendering) on multiple GPUs. The really exciting thing about this feature is that this can occur even if the GPUs are from different vendors!





«Prev 1 2 3 4 5 6 7 8 9 10 11 12 Next»

Most Recent Comments

04-04-2016, 16:34:06

Relayer
Do you have 390(X), 970, 980 cards on hand to test? It would be good to see how these perform since so many gamers own them. In some games lately Hawaii has been getting pretty close to Fury(X) performance.

Thanks,Quote

04-04-2016, 16:44:49

WYP
Quote:
Originally Posted by Relayer View Post
Do you have 390(X), 970, 980 cards on hand to test? It would be good to see how these perform since so many gamers own them. In some games lately Hawaii has been getting pretty close to Fury(X) performance.

Thanks,
Sadly I do not have an R9 390 or GTX 970 for performance testing.

All of the GPUs that I use for testing have been bought and paid for by me the writer and were not samples from an external party or sponsor. Hopefully we can get hold of more GPUs for gaming content in the future, especially when the next generation of GPUs are released.Quote

04-04-2016, 21:33:03

NeverBackDown
Quote:
Right now only AMD GCN GPUs support Asynchronous Compute in their GPU drivers, though Nvidia is rumored to be adding support for this function to Maxwell in the future with a driver update, though this remains unconfirmed by Nvidia.
AMD supports it on a hardware level as well as driver level. Nvidia won't be releasing a driver for it, driver can't make up for hardware losses, it's not possible for Nvidia to implement such a feature.

I find it kind of funny that now AMD in DX11 are either slightly behind or just ahead. Nvidia really are struggling with this title, explains why they called Oxide out before. Hopefully as they push out more content it gets more optimized and less CPU limited in future updates/patches.Quote

05-04-2016, 08:32:58

SPS
I'd be more interested to see different CPUs used, from both Intel and AMD's offerings. Though I do appreciate that you don't have access to everything or necessarily the time either.

Quote:
Originally Posted by NeverBackDown View Post
AMD supports it on a hardware level as well as driver level. Nvidia won't be releasing a driver for it, driver can't make up for hardware losses, it's not possible for Nvidia to implement such a feature.

I find it kind of funny that now AMD in DX11 are either slightly behind or just ahead. Nvidia really are struggling with this title, explains why they called Oxide out before. Hopefully as they push out more content it gets more optimized and less CPU limited in future updates/patches.
Oxide most likely focused on GCN optimization which kind of explains why Nvidia benefit on DX11. Not sure how you know Nvidia can't support async compute, they don't really share architecture notes.Quote

05-04-2016, 11:18:59

NeverBackDown
Quote:
Originally Posted by SPS View Post
I'd be more interested to see different CPUs used, from both Intel and AMD's offerings. Though I do appreciate that you don't have access to everything or necessarily the time either.



Oxide most likely focused on GCN optimization which kind of explains why Nvidia benefit on DX11. Not sure how you know Nvidia can't support async compute, they don't really share architecture notes.
Even in dx11, they aren't much better as everything gets higher resolution or settings. I doubt it's mostly AMD focused, it uses asynchronous compute. Nvidia doesn't have it and therefore probably results to context switching to do both compute and graphic work so it adds latency and therefore decrease framerate. AMD called out Nvidia at GDC that you can't support it at a driver level. In addition, it's been what 6 months and we've had no comment or hints from Nvidia about this "rumored" magic driver. I think it's more likely that got started by people saying, "wait for them to release a driver for the game". I don't even think Nvidia has a proper driver for it yet.. or not for a while. Which makes sense since they called out Oxide saying its not represenitive of a real dx12 title and begging them not to use asynchronous compute. That's just them being sore losers tbh. Nothing wrong with admitting that they can't support it but will try to get the best performance possible anyway. They haven't done this for any other dx12 title, it's just because they lose by far in this oneQuote
