Phison’s next-gen PCIe 4.0 SSD controller delivers 7GB/s transfer speeds
Phison’s next-gen PCIe 4.0 SSD controller delivers 7GB/s transfer speeds
Today’s Phison PS5016-E16 controller is used in all consumer-grade PCIe 4.0 SSDs on the market, packing support for maximum read/write speeds of 5,000/4,400 MBps respectively and a maximum of 750K/750K Random Read/Write IOPS at 2.6W of power. With the PS5018-E18, Phison plans to offer 7GB/s read/write speeds, and a maximum of 1,000K read/write IOPS.Â
To do this, Phison has moved from TSMC’s 28nm lithography to the company’s newer 12nm manufacturing process, upped their controller power consumption to a maximum of around 3W and have packed into their silicon three 32-bit ARM Cortex R5 processors instead of two. The Speed of each memory channel has also been increased from 800 MT/s to 1200MT/s, enabling much of the controller’s speed increase.Â
This new controller will also support a DDR4/LPDDR4 cache and will be able to support TLC and QLC NAND. Phison will also jump to the NVMe 1.4 protocol with this controller.Â
In basic terms, Phison hopes to move close to the limits of PCIe 4.0 with their next-generation PS5018-E18 controller, support a maximum of eight memory channels and up to 8TB of memory.Â
Below are the specifications of Phison’s existing PS5016-E16 SSD controller. These impressive speeds will look slow when compared to Phison’s next-generation offerings.Â
Â
At the Flash Memory Summit, Phison has confirmed that their new PS5018-E18 controller will become available in Q2 2020.Â
You can join the discussion on Phison’s next-generation PVie 4.0 SSD controller on the OC3D Forums.Â
