XFX’s first custom Radeon RX 5700 XT graphics card has been pictured, revealing to the world one of the first, non-reference Radeon Navi graphics cards.

The images below come our way via expreview, who have stated that they cannot confirm the specifications of the graphics card because of a non-disclosure agreement (NDA). Beyond that, the publication cannot disassemble the graphics card or release performance data for the GPU.

The images below confirm that XFX’s custom Radeon RX 5700XT features two axial fans and ships with a form factor that’s wider than two PCIe slots. The graphics card also features a backplate, which features elements which are bent to cover the side of the graphics card.



XFX's custom Radeon Navi RX 5700 XT has been Pictured - Detailed images released
While the image below is unclear, it looks like XFX’s custom Radeon RX 5700XT features the same display output configuration as AMD’s reference RX 5700 series graphics cards, offering a single HDMI 2.0b connection and three DisplayPort 1.4 connectors.

Given the twin-fan nature of this graphics card, it is likely that this graphics card will be XFX’s next Double Dissipation series graphics card. Unlike XFX’s last generation offerings, their RX 5700 DD will not feature carbon-fibre elements.

XFX's custom Radeon Navi RX 5700 XT has been Pictured - Detailed images released

XFX’s custom RX 5700 XT graphics card will release in mid-August. At this time the exact specifications of the graphics card are unknown.
